Battery Box

Follow
Will Walker

Hello, I've got the model SC-BAT-BX2 battery box and it stopped working. It will show the volts of the battery, but its not charging. I have tried it on 2 different Spartan cameras along with 2 different batteries. I know it should be a plug-n-play, but is there anything else I can check??

0

Comments

13 comments

Sort by Date Votes
  • John Lockburner
    • Edited

    Check the wires that run from the battery to the box, there's a tab you squeeze and can unplug that wire(s) and plug it back in. I think there's a few other plugs to check as well.

    1
    Comment actions Permalink
  • Will Walker

    Thanks John I tried unplugging and re-plugging (I work in IT hahaha, so I'm used to that), but I will try again. Thanks!

    0
    Comment actions Permalink
  • John Lockburner

    When you say it's not charging are you meaning that the battery isn't charging from a solar panel or it won't power the camera? What is the voltage of the battery in the box?

    0
    Comment actions Permalink
  • Will Walker

    sorry I should have been more clear. When I have the battery connected, it is showing on the battery box that is has a charge, but when I connect it to the camera, it doesn't get any power

    0
    Comment actions Permalink
  • John Lockburner

    Do you have a multi meter?

    0
    Comment actions Permalink
  • Will Walker

    No sir I dont. This is what I'm seeing now. Its plugged in, has power, but nothing on the screen (its on setup so I should see something)

    0
    Comment actions Permalink
  • John Lockburner

    Your battery in the box is dead, I think that's causing your problem

    1
    Comment actions Permalink
  • Will Walker

    gotcha, let me charge it over night and see what happens. Thanks again for your help!

    0
    Comment actions Permalink
  • Will Walker

    Thanks John that did the trick. You would think that 4v of power would be sufficient but I'm just glad thats all it was. Thank you again!

    0
    Comment actions Permalink
  • John Lockburner
    • Edited

    4v isn't even close for a 6v camera, actually once you get close to 5v you'll start seeing some inconsistency with the sending. 4 volts is also not good for an SLA battery, when they get too low it can damage the battery itself. Glad that's all it was

    1
    Comment actions Permalink
  • Elizabeth Swoope

    5.7 volts is what will show on the app when the battery is fully charged (6V or higher). You will generally get pics at 5.1 volts (battery box may show 5.6, 5.7, 5.8), but that can be dicey when the battery has been at that voltage for a while. Whenever you see that battery dropping to 5.1 (hopefully you won’t with a solar panel on it), you’ll want to change it pretty soon.

    1
    Comment actions Permalink
  • Jimmy Starnes

    Hey I have a battery box that started getting water in it. I noticed battery was showing low and when I went and checked the battery box had a good amount of water in it. The box doesn’t seem like it’s working properly now so was just looking for advice.  The boxes are fairly expensive for this to happen.   Thanks jimmy

    0
    Comment actions Permalink
  • John Lockburner

    I would email support@spartancamera.com and let them know

    0
    Comment actions Permalink
